TKAACS All-Aluminum Center Frame Step Deck
TKAACS All-Aluminum Center Frame Step Deck
This step deck trailer features superior corrosion resistance, all-aluminum framing, and zinc-plated or armor-coated steel components, making this piece of equipment the most dependable, long-lasting step deck trailer you’ll ever own.
The all-aluminum center frame step deck can accommodate your toughest payloads, including short, tall, and any cargo configurations. It’s engineered for superior load-hauling strength combined with competitive low deck heights.
Find Your Specialized Solution
Call our toll-free number 800-843-3324
| STANDARD EQUIPMENT | TK80AACS-34 | TK80AACS-38 | TK80AACS-40 |
|---|---|---|---|
| Base Weight | 8,635 lbs. | 8,947 lbs. | 9,059 lbs. |
| Capacity | 80K Distributed | 80K Distributed | 80K Distributed |
| Loaded Deck Height | 34” | 38” | 40” |
| Loaded Ground Clearance | 9” | 13” | 15” |
| Overall Width | 102” | 102” | 102” |
| Overall Length | 47’ 10” | 47’ 10” | 47’ 10” |
| Kingpin Setting | 14” | 14” | 14” |
| Fifth Wheel Height | 48” – 50” | 48” – 50” | 48” – 50” |
| Upper Deck Length | 10’ | 10’ | 10’ |
| Concentrated Load Rating | 60K in 10’ | 60K in 10’ | 60K in 10’ |
| Aluminum Decking w/ (3) Flush Apitong Nailers | X | X | X |
| Cross Member Spacing (Main/Upper) | 12’/18” | 12’/18” | 12’/18” |
| Suspension | Holland CB25U | Holland CB25U | Holland CBX23U |
| Suspension Configuration | Tandem | Tandem | Tandem |
| Suspension Spacing | 50” | 50” | `50” |
| Rear Axle Location | Wheels Back | Wheels Back | Wheels Back |
| Anti-Lock Braking System | 2S1M | 2S1M | 2S1M |
| Drum Brakes | 12 ¼ x 7 ½ | 12 ¼ x 7 ½ | 16 ½ x 7 |
| Brake Rating | 20K | 20K | 20K |
| Manual Raise/Lower w/Gauge Enclosure | X | X | X |
| Wheels | 6.75 x 17.5 Steel | 8.25 x 19.5 Steel | 8.25 x 22.5 Steel |
| Tires | 235/75R17.5 | 265/70R19.5 | 255/70R22.5 |
| 2-Speed Landing Gear | X | X | X |
| Flag Holders | 3/side | 3/side | 3/side |
| Sealed Electrical System | X | X | X |
| LED Lights | X | X | X |
| DOT Required Lights w/Mid-Turn & 3rd Tail Light | X | X | X |
| Document Holder | X | X | X |
| Red and White Conspicuity Markings | X | X | X |
| Standard TK Decals | X | X | X |
| 3/8” x 3” Aluminum Rub Rail w/ Double Chain Spools | X | X | X |
| Stake Pockets (24” O.C.) – Sides & Front | X | X | X |
| Full-Length Hook Track | X | X | X |
| Anti-Corrosion Barrier Between Aluminum and Steel | X | X | X |
| Zinc Coated Steel Components | X | X | X |
| Armor Coated Landing Gear & Suspensions | X | X | X |
| Dock Bumpers | X | X | X |
